STRIKER™ Vivid 4cv, WW (with GT20-TM transducer),

Availability: In stock

- +
SKU: 010-02550-01 Category: Tag:

See fish and structure in maximum detail when you pick your display color, your location and your sonar for your day on the water with the STRIKER Vivid 4cv fishfinder with transducer. For more Garmin Product Click Here.

Links
2-stroke-engine-oil Garmin STRIKER Vivid 4cv Guide

General
DIMENSION 3.9” x 6.9” x 1.8” (9.8 x 17.4 x 4.5 cm)
INPUT Keyed
DISPLAY SIZE 2.1″ x 3.7″ (5.4 x 9.5 cm); 4.3″ diag, (10.9 cm)
DISPLAY RESOLUTION 272 X 480 pixels
DISPLAY TYPE QSVGA
WEIGHT 0.7 lbs (320 g)
WATERPROOF IPX7
MOUNTING OPTIONS flush, tilt/swivel
Maps & Memory
WAYPOINTS/FAVORITES/LOCATIONS 5000
TRACK POINTS 50,000
TRACKS 50
NAVIGATION ROUTES 100
Sensors
HAS BUILT-IN RECEIVER Yes
RECEIVER Traditional: 50/77/200 kHz
CHIRP (mid and high)
ClearVü 260/455/800 kHz
GPS Yes
SUPPORTS WAAS Yes
Optional Map Support
GARMIN QUICKDRAW CONTOURS Yes
Sonar Features & Specifications
DISPLAYS SONAR Yes
TRADITIONAL SONAR (DUAL FREQUENCY/BEAM) Built-in
CLEARVÜ Yes
FREQUENCY Traditional: 50/77/200 kHz
CHIRP (mid and high)
ClearVü 260/455/800 kHz
BOTTOM LOCK (SHOWS RETURN FROM THE BOTTOM UP) Yes
WATER TEMPERATURE LOG Yes
Connections
4-PIN TRANSDUCER PORTS 1
Electrical Features
POWER INPUT 12 to 20 Vdc
TYPICAL CURRENT DRAW 0.40 A
MAX CURRENT DRAW 1.5 A
POWER CONSUMPTION 4.8
TRANSMIT POWER 300 W (RMS)
Fish finder Features
SPLIT-SCREEN ZOOM Yes
FISH SYMBOL ID (HELPS IDENTIFY FISH TARGETS) Yes
AUTOGAIN TECHNOLOGY (MINIMIZES CLUTTER; MAXIMIZES TARGETS) Yes
ADJUSTABLE DEPTH LINE (MEASURES DEPTH OF UNDERWATER OBJECTS) Yes
A-SCOPE (REAL TIME DISPLAY OF FISH PASSING THROUGH TRANSDUCER BEAM) Yes
WATER TEMPERATURE SENSOR INCLUDED Yes
DEPTH RANGE SHADING Yes
