General | |
| Physical dimensions (diameter x depth) | 12″ sports subwoofer: 14.02″ x 10″ (356 x 254 mm) 10″ classic subwoofer: 10.83″ x 6.38″ (275 x 162 mm) 10″ sports subwoofer: 10.83″ x 6.77″ (275 x 172 mm) |
| Weight | 12″ sports subwoofer: 24.1 lbs (10.93 kg) 10″ CRGBW sports subwoofer: 11.3 lbs (5.12 kg) 10″ classic subwoofer: 11.2 lbs (5.06 kg) 10″ sports subwoofer: 11 lbs (4.98 kg) |
| Water and dust rating | IP65 |
| Peak power (Watts) | 12″ subwoofer: 1400 watts 10″ subwoofer: 600 watts |
| RMS power rating (watts) | 12″ subwoofer: 700 watts 10″ subwoofer: 300 watts |
| Sensitivity (1 watt @ 1 metre) | 86 dB |
| Magnetic structure | 12″ subwoofer: 114 oz 10″ subwoofer: 68 oz |
| Frequency response | 12″ subwoofer: 20 Hz–2 kHz 10″ subwoofer: 30 Hz–2 kHz |
| Nominal impedance | 4 ohm |
| Recommended amplifier power (watts RMS) | 12″ subwoofer: 200–1000 watts 10″ subwoofer: 50–600 watts |
| LED lighting | yes, CRGBW (sports style with LED models only) |
| LED supply voltage | 10.8–16 VDC (sports style with LED models only) |
| LED load current @14.4 VDC (max) | 300 mA (sports style with LED models only) |
| Operating temperature range | 32–122 degrees F (0–50 degrees C) |
| Voice coil diameter | 12″ subwoofer: 4″ 10″ subwoofer: 2″ |
| Cone material | Polypropylene cone with rubber surround |
| Compass-safe distance | 12″ subwoofer: 181″ (460 cm) 10″ subwoofer: 205″ (520 cm) |
| Subwoofer connection | Flying lead with water-resistant 2-way connector, 5.9″ (150 mm) |
| LED connection (sports style with LED models only) | Flying lead with water-resistant 6-way connector, 5.9″ (150 mm) |
| Warranty | 3 years |
Mounting Dimensions | |
| Mounting diameter clearance | 12″ subwoofer: 12.05″ (306 mm) 10″ subwoofer: 8.78″ (223 mm) |
| Mounting depth clearance | 12″ subwoofer: 8.15″ (207 mm) 10″ subwoofer: 5.24″ (133 mm) |
Optimum enclosure recommendations | |
| Sealed enclosure volume (fully filled with absorption material) | 12″ subwoofer: 2.12 cubic ft (60 L) 10″ subwoofer: 0.95 cubic ft (27 L) |
| Ported (vented) enclosure volume (lined with absorption material) | 12″ subwoofer: 8.83 cubic ft (250 L) 10″ subwoofer: 1.6 cubic ft (45 L) |
| Port diameter | 12″ subwoofer: 4″ (101.6 mm) 10″ subwoofer: 4.1″ (104 mm) |
| Port length | 12″ subwoofer: 5″ (127 mm) 10″ subwoofer: 10.43″ (265 mm) |
