| General 4cv | |
| DIMENSION | 3.9” x 6.9” x 1.8” (9.8 x 17.4 x 4.5 cm) |
| WEIGHT | 0.7 lbs (0.3 kg) |
| WATERPROOF | IPX7 |
| DISPLAY TYPE | QSVGA |
| DISPLAY RESOLUTION | 272 X 480 pixels |
| Sonar Features | |
| FREQUENCY | Traditional: 50/77/200 kHz |
| CHIRP (mid and high) | |
| ClearVü 260/455/800 kHz | |
| TRANSMIT POWER | 300 W (RMS) |
| BOTTOM LOCK (SHOWS RETURN FROM THE BOTTOM UP) | Yes |
| WATER TEMPERATURE LOG | Yes |
| Fishfinder Features | |
| SPLIT-SCREEN ZOOM | Yes |
| FISH SYMBOL ID (HELPS IDENTIFY FISH TARGETS) | Yes |
| AUTOGAIN TECHNOLOGY (MINIMIZES CLUTTER; MAXIMIZES TARGETS) | Yes |
| ADJUSTABLE DEPTH LINE (MEASURES DEPTH OF UNDERWATER OBJECTS) | Yes |
| A-SCOPE (REAL TIME DISPLAY OF FISH PASSING THROUGH TRANSDUCER BEAM) | Yes |
| WATER TEMPERATURE SENSOR INCLUDED | Yes |
| Additional | |
| ADDITIONAL | One 4-pin transducer port |
| Quickdraw Contours | |
| Integrated GPS | |
| Mark Waypoints | |
| Course over Ground (COG) | |
| Current draw @ 12V: 0.40A | |
| General 5cv | |
| DIMENSION | 7.4’’ x 4.5’’ x 2.1’’ (18.8 x 11.6 x 5.4 cm) |
| WEIGHT | 1.0 lb (0.5 kg) |
| WATERPROOF | IPX7 |
| DISPLAY TYPE | WVGA color |
| DISPLAY RESOLUTION | 800 x 480 pixels |
| Sonar Features | |
| FREQUENCY | Traditional: 50/77/200 kHz |
| CHIRP (mid and high) | |
| ClearVü 260/455/800 kHz | |
| TRANSMIT POWER | 500 W (RMS) |
| BOTTOM LOCK (SHOWS RETURN FROM THE BOTTOM UP) | Yes |
| WATER TEMPERATURE LOG | Yes |
| Fishfinder Features | |
| SPLIT-SCREEN ZOOM | Yes |
| FISH SYMBOL ID (HELPS IDENTIFY FISH TARGETS) | Yes |
| AUTOGAIN TECHNOLOGY (MINIMIZES CLUTTER; MAXIMIZES TARGETS) | Yes |
| ADJUSTABLE DEPTH LINE (MEASURES DEPTH OF UNDERWATER OBJECTS) | Yes |
| A-SCOPE (REAL TIME DISPLAY OF FISH PASSING THROUGH TRANSDUCER BEAM) | Yes |
| WATER TEMPERATURE SENSOR INCLUDED | Yes |
| Additional | |
| ADDITIONAL | One 4-pin transducer port |
| Quickdraw Contours | |
| Integrated GPS | |
| Mark Waypoints | |
| Course over Ground (COG) | |
| Current draw @ 12V: 0.40A | |
| General cv7 | |
| DIMENSION | 9.3” x 5.5” x 2.3” (23.5 x 14.0 x 5.8 cm) |
| WEIGHT | 1.7 lbs (0.8 kg) |
| WATERPROOF | IPX7 |
| DISPLAY TYPE | WVGA color |
| DISPLAY RESOLUTION | 800 x 480 pixels |
| Sonar Features | |
| FREQUENCY | Traditional: 50/77/200 kHz |
| CHIRP (mid and high) | |
| ClearVü 260/455/800 kHz | |
| TRANSMIT POWER | 500 W (RMS) |
| BOTTOM LOCK (SHOWS RETURN FROM THE BOTTOM UP) | Yes |
| WATER TEMPERATURE LOG | Yes |
| Fishfinder Features | |
| SPLIT-SCREEN ZOOM | Yes |
| FISH SYMBOL ID (HELPS IDENTIFY FISH TARGETS) | Yes |
| AUTOGAIN TECHNOLOGY (MINIMIZES CLUTTER; MAXIMIZES TARGETS) | Yes |
| ADJUSTABLE DEPTH LINE (MEASURES DEPTH OF UNDERWATER OBJECTS) | Yes |
| A-SCOPE (REAL TIME DISPLAY OF FISH PASSING THROUGH TRANSDUCER BEAM) | Yes |
| WATER TEMPERATURE SENSOR INCLUDED | Yes |
| Additional | |
| ADDITIONAL | One 4-pin transducer port |
| Wireless Connectivity: Yes | |
| Quickdraw Contours | |
| Integrated GPS | |
| Mark Waypoints | |
| Course over Ground (COG) | |
| Current draw @ 12V: 0.55A | |
| General cv9 | |
| DIMENSION | 11.1” x 6.5” x 2.4” (28.2 x 16.5 x 6.0 cm) |
| WEIGHT | 2.4 lbs (1.1 kg) |
| WATERPROOF | IPX7 |
| DISPLAY TYPE | WVGA color |
| DISPLAY RESOLUTION | 800 x 480 pixels |
| Sonar Features | |
| FREQUENCY | Traditional: 50/77/200 kHz |
| CHIRP (mid and high) | |
| ClearVü and SideVü 260/455/800 kHz | |
| TRANSMIT POWER | 500 W (RMS) |
| BOTTOM LOCK (SHOWS RETURN FROM THE BOTTOM UP) | Yes |
| WATER TEMPERATURE LOG | Yes |
| Fishfinder Features | |
| SPLIT-SCREEN ZOOM | Yes |
| FISH SYMBOL ID (HELPS IDENTIFY FISH TARGETS) | Yes |
| AUTOGAIN TECHNOLOGY (MINIMIZES CLUTTER; MAXIMIZES TARGETS) | Yes |
| ADJUSTABLE DEPTH LINE (MEASURES DEPTH OF UNDERWATER OBJECTS) | Yes |
| A-SCOPE (REAL TIME DISPLAY OF FISH PASSING THROUGH TRANSDUCER BEAM) | Yes |
| WATER TEMPERATURE SENSOR INCLUDED | Yes |
| Additional | |
| ADDITIONAL | One 4-pin transducer port |
| One 4-pin SideVü transducer port | |
| Wireless Connectivity: Yes | |
| Quickdraw Contours | |
| Integrated GPS | |
| Mark Waypoints | |
| Course over Ground (COG) | |
| Current draw @ 12V: 0.75A | |
